Jinan Baisite Bearing Co., Limited

There are cylindrical and tapered bore two structures, cage made of steel sheet, synthetic resin. It features an outer ring raceway spherical shape, with auto-Mind, can compensate for misalignment and shaft deflection caused by the error, but the inner and outer rings relative inclination of not more than 3 degrees.

Bearing Series	22 Series
Bearing Model	22314
Dimension	70×150×51 mm
Weight	4.48 kg
Material	Gcr15 /chrom steel
Structure	Self-aligning ball bearing

We can provide more models:

Series	Model Number	d(mm)	D(mm)	B(mm)	Series	Model Number	d(mm)	D(mm)	B(mm)
21300 series	21307	35	72	23	22200 series	22205	25	52	18
	21308	40	90	23		22206	30	62	20
	21309	45	100	25		22207	35	72	23
	21310	50	110	27		22208	40	80	23
	21311	55	120	29		22209	45	85	23
	21312	60	130	31		22210	50	90	23
	21313	65	140	33		22211	55	100	25
	21314	70	150	35		22212	60	110	28
	21315	75	160	37		22213	65	120	31
23000 series	23020	100	150	37	24000 series	24015	75	115	40
	23022	110	170	45		24018	90	140	50
	23024	120	180	46		24020	100	150	50
	23026	130	200	52		24022	110	170	60
	23028	140	210	53		24024	120	180	60
	23030	150	225	56		24026	130	200	69
	23032	160	240	60		24028	140	210	69
	23034	170	260	67		24030	150	225	75
	23036	180	280	74		24032	160	240	80
22300 series	22307	35	80	31	24100 series	24120	100	165	65
	22308	40	90	33		24122	110	180	69
	22309	45	100	36		24124	120	200	80
	22310	50	110	40		24126	130	210	80
	22311	55	120	43		24128	140	225	85
	22312	60	130	46		24130	150	250	100
	22313	65	140	48		24132	160	270	109
	22314	70	150	51		24134	170	280	109

If you have any requirements regarding bearings, please feel free to contact us at any time.

Can I help you?

We will serve you

Products

Products

The bearings have a large load capacity and are suitable for applications with vibration and impact loads. CA,CC,E,E1,VA405 cage are available.
